Mitsubishi L2C Service Manual

GENERAL
1-13
Electrical
system
Voltage - polarity 12V - negative (-) ground, 24V - negative (-) ground
Starter (1)
Type M000T60481
Manufacturer Mitsubishi Electric Corporation
Pinion engagement type Pinion shift (reduction type)
Output 12V - 1.2 kW
Number 1
Pinion/ring gear ratio 14/106
Starter (2)
Type M001T68381
Manufacturer Mitsubishi Electric Corporation
Pinion engagement type Pinion shift (reduction type)
Output 12V - 1.7 kW
Number 1
Pinion/ring gear ratio 14/106
Starter (3)
Type M002T66071
Manufacturer Mitsubishi Electric Corporation
Pinion engagement type Pinion shift (reduction type)
Output 24V - 3.2 kW
Number 1
Pinion/ring gear ratio 15/106
Alternator (1)
Type A007TA0171B
Type
Three-phase current generator,
integral with IC regulator
Manufacturer Mitsubishi Electric Corporation
Output 12V - 40A
Rated voltage generating speed
5000 min
-1
(at 13.5V, 37A, when hot)
Regulator adjusting voltage 14.7 ± 0.3V
Alternator (2)
Type A007TA8271A
Type
Three-phase current generator,
integral with IC regulator
Manufacturer Mitsubishi Electric Corporation
Output 24V - 25A
Rated voltage generating speed
5000 min
-1
(at 27.0V, 22A, when hot)
Regulator adjusting voltage 28.5 ± 0.5V
Glow plug (1)
Type Sheathed
Rated voltage - current 10.5V - 9.7A ± 1.0A (30-second duration)
Glow plug (2)
Type Sheathed
Rated voltage - current 22.5V - 4.8A ± 0.5A (30-second duration)
Table 1-2 Specifications of L3A, L3C and L3E (3 / 4)
