Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
GENERAL ELECTRICAL SYSTEM
ELECTRICAL SYSTEM
31 GENERAL
31.1 Specifications
1
1. All specifications are subject to change without any prior
notice.
Description
Specification
L2 L3
STARTER
Model M000T60481 M001T68381
Type Solenoid shift type
Nominal output 12V-1.2 kW 12V-1.7 kW
No-load characteristic
11V/90A or less
2500 rpm or more
11V/110A or less
2400 rpm or more
Load characteristic
7.5V/300A
10.5 N·m (1.07 kgf·m) [7.7
lbf·ft] or more
850 rpm or more
7.7V/400A
16.0 N·m (1.63 kgf·m) [11.8
lbf·ft] or more
740 rpm or more
ALTERNATOR
Model
L2 L3
AB A B
A000T25371
A007TA01718
(NEW TYPE)
A000T25371
A007TA01718
(NEW TYPE)
Type Alternator with built-in IC regulator
Nominal output 12V-40A 12V-40A
Output performance, hot
21A/2500 rpm
37A/5000 rpm
21A/2500 rpm
37A/5000 rpm
GLOW PLUG
Model Y–145T
Type Sheath type, quick-heating
Rated voltage 10.5V DC
Current 9.7A±1.0A (when rated voltage is applied for 30 seconds)
Resistance at normal temperatures 0.2
GLOW PLUG
RELAY
Model G71SP
Rated voltage, V DC 12
Continuous rating 1 minute
Resistance in coil, 13
CONTROL
TIMER UNIT
Model YM-1C
Input voltage range, V DC 9 to 15
Load Solenoid (resistance in coil: 1.7 minimum)
Table 49 Specifications
