Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
EXTERNAL VIEW
ENGLISH
GENERAL
2.2 Engine L3
Engine hangers
Water pump
Air vent screw
Fuel injection pump
Side oil filler
Oil pressure switch
FRONT
Dipstick
Oil drain plug
Fuel injector
Air inlet cover
Stop solenoid
Fuel filter
Coolant drain plug
REAR
Oil filter
RIGHT SIDE VIEW
LEFT SIDE VIEW
REAR
FRONT
Oil pan
Crankshaft pulley
V-belt
Alternator
Fan
Thermoswitch
Thermostat housing
Top oil filler
Exhaust manifold
Flywheel housing
Flywheel
Starter
