Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
INJECTION NOZZLE
ENGLISH
FUEL SYSTEM
2. Remove the injection nozzle assembly from the
cylinder head.
22.3 Disassembly
If the removed nozzle assembly is assumed defective,
disassemble the assembly and repair or replace the
defective parts.
1. Grip the nozzle holder body in a vise. Loosen the
retaining nut. Never vise the retaining nut to
prevent deformation.
2. Remove the shim washer, pressure spring,
distance piece and nozzle assembly.
CAUTION
a. Attach an identification-number tag to the
removed injection nozzle.
b. Plug the openings, to prevent entering of dust,
water and other foreign particles into the pipes
and combustion chamber.
c. Do not mix the parts of any nozzle assy with
others, but keep the parts of each nozzle
assembly as a unique combination.
CAUTION
Scrape off carbon deposit with a wooden piece. Keep
the removed parts immersed in washing oil
(kerosene). Pay special attention not to scratch the
needle valve in the nozzle assembly.

Mitsubishi L2E Specifications

General

Engine Model	L2E
Number of Cylinders	2
Starting System	Electric starter
Lubrication System	Forced lubrication by trochoid pump
Cooling System	Water-cooled
