Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ALTERNATOR AND DYNAMO
ENGLISH
ELECTRICAL SYSTEM
ELECTRICAL SYSTEM
33 ALTERNATOR AND
DYNAMO
33.1 Structure
Disassembly sequence
1. Pulley
2. Front bracket assembly
3. Front bearing
4. Rotor assembly
5. Rear bearing
6. Stator
7. Terminal set
8. Regulator assembly
9. Rectifier assembly
10. Rear bracket assembly
4
6
3
2
1
5
10
8
9
7
Figure 133 Alternator component parts
