Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
CYLINDER BLOCK ENGINE MAIN PARTS
ENGINE MAIN PARTS
17 CYLINDER BLOCK
17.1 Disassembly
Disassembly sequence
1. Cylinder block
2. Front plate
3. Bearing cap
4. Cover
5. Main bearing
6. Starter bracket
7. Rear oil seal
8. Oil seal case
9. Idler gear shaft
10. Oil filter shaft
11. Oil level gage guide
1
1
7
6
10
11
9
8
2
3
5
4
5
5
5
3
3
3
3
3
3
5
5
5
Figure 83 Cylinder block component parts
