18 / 155
Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
SPECIFICATIONS GENERAL
GENERAL
4 SPECIFICATIONS
1
1 All specifications are subject to change without any prior notice.
System Item
Model
L2A L2C L2E L3A L3C L3E
ENGINE
PROPER
Type 4-cycle, water-cooled, vertical, overhead valve, diesel engine
Combustion chamber Swirl chamber type
No. of cylinders 2 3
Bore x Stroke (mm) 65x70 70x70 76x70 65x70 70x70 76x70
Total displacement (l) 0.464 0.538 0.635 0.696 0.808 0.952
Compression ratio 23
Firing order 1 - 2 1 - 3 - 2
Dry weight (kg) 61 75
LUBRICATING
SYSTEM
Lubricating method Forced lubrication
Oil pump Gear type
Oil filter Paper element type
Oil capacity:
FULL level/EMPTY level (l)
(Exclusive of oil filter capacity 0.5 l )
2.4/1.4 3.0/1.5 or 3.6/1.8 or 4.8/3.0
FUEL SYSTEM
Fuel injection pump Bosch type NC
Nozzle Throttle type
Fuel injection pressure 140 kgf/cm
2
(1,991 psi) [13,729 kPa]
Fuel to be used Diesel fuel; see chapter 7
Governor Centrifugal weight type
INTAKE SYSTEM Air cleaner Paper-element type or Oil-bath type
COOLING
SYSTEM
Cooling method Forced circulation of water
Water pump Centrifugal type
Coolant capacity (l)
(Engine proper only)
1.2 1.8
ELECTRICAL
SYSTEM
Starter (V - kW) Solenoid shift type (12-1.2 or 12-1.6 or 12-1.7)
Alternator (V - A) AC generator (12-40)
Glow plug Sheathed type
Battery
(capacity depends on application)
12V, 45 Ah or more 12V, 60 Ah or more
Table 3 Specifications
