76 / 155
Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
CRANKSHAFT ENGINE MAIN PARTS
16.4 Replacement of crankshaft
rear oil seal
When reassembling the piston and connecting rod and
installing the piston-and-rod assemblies in the cylinder
block, pay attention to the following:
1. Pry the oil seal out with a screwdriver.
2. Drive in a new oil seal to the oil seal case.
Description Standard
Main bearing cap bolt
49.0 to 53.9 (5.0 to 5.5)
[36.17 to 39.78]
Rod bearing cap nut
31.4 to 34.3 (3.2 to 3.5)
[23.15 to 25.32]
Table 33 Tightening torque N·m (kgf·m) [lbf·ft]
Description Standard
Main bearing 0.10 [0.0039]
Rod bearing 0.15 [0.0059]
Table 34 Oil clearance (mm [in.])
