Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
EXTERNAL VIEW GENERAL
GENERAL
2 EXTERNAL VIEW
2.1 Engine L2
Engine hangers
Water pump
Air vent screw
Fuel injection pump
Side oil filler
Oil pressure switch
RIGHT SIDE VIEW
FRONT
Dipstick
Coolant drain plug
Oil drain plug
Fuel injector
Air inlet cover
Stop solenoid
Fuel filter
Oil filter
REAR
LEFT SIDE VIEW
REAR
FRONT
Oil pan
Crankshaft pulley
Thermostat housing
Thermoswitch
Alternator
Fan
V-belt
Top oil filler
Exhaust manifold
Flywheel housing
Flywheel
Starter

Table of Contents

Other manuals for Mitsubishi L2E

Preview: Operation & Maintenance Manual
Operation & Maintenance Manual89 pages
Preview: Operation Manual
Operation Manual44 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitsubishi L2E and is the answer not in the manual?

Mitsubishi L2E Specifications

General IconGeneral
Engine ModelL2E
Number of Cylinders2
Starting SystemElectric starter
Lubrication SystemForced lubrication by trochoid pump
Cooling SystemWater-cooled
