Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
GENERAL
ENGLISH
ELECTRICAL SYSTEM
< ETR type stop solenoid >
1. Figure indicates a nominal size of automotive low-tension line (JIS C 3406).
2. This schematic shows the electrical system of the standard engine equipped with a key shut down solenoid and glow plugs.
Glow plug
Pilot lamp
MM201-124
Themo switch
MC880-900
Safety relay
MM130-767
Model
Battery
Starter
Alternator
Glow relay
MM431-28201
Pilot lamp
MM201-123
Glow timer
MM431-762
Diode
MM434-062
Pressure switch
MM130-066
Charge pilot
MM201-122
Alternator
Starter switch
30890-05200
Pilot lamp
MM201-124
Control timer
I6A12-02001
Connection of
starter switch
Terminal
Position
Fuel pump
30A60-00200
Starter relay
32A66-19100
Starter
Battery switch
05125-00102
Battery
0,85 mm
2
or more
60 mm
2
or more
3 mm
2
or more
5 mm
2
or more
Diode
MM434-062
L2E
12V-48Ah or more
12V-1.2kW
12V-40A
L3E
12V-60Ah or more
12V-1.7kW
R
1
OFF
ACC
St
BR
1
ACC
R
2
B
r
C
Hold (White)
Solénoid (ETR)
Common (Blue)
Pull in (Red)
Controller
31A66-06100
N.C.(B Type) relay
