Methods of creating stitching data
[9]-6
9. Confirming the data
* Confirm the data.
Press the jog keys ( ),
so the sewing machine movement can
be confirmed. (Even if the data input
has not been completed, if the data
input last has been set, the movement
can be confirmed in the same
manner.)
* If the confirmed data is correct, save
the data. (Refer to [5] Reading, writing
and erasing data (floppy disk) and [6]
Reading, writing and erasing data
(internal memory).)
* If the data must be modified, refer to
section [12] Modification mode
Modifying the stitching data.
Memo
The size display of the pattern data is explained when "The arc" or "The Circle" is made and the
image display is pushed from a standard screen, the image display screen is opened.
For instance, when made the 20mm half circle data but the size display is not
[20.0] Y axially, is [19.9] it like the above figure.
The reason for this is that the displayed value is calculated with an actual sewing
point. Tries to make the circle or the circular arc which passes input point as shown
in the figure below, the data is made according to the specified stitch length, it is
not match that sewing point and input point (A). There is difference (B) of the figure
below because the value is calculated with the sewing point.
