How To Set the Lead and Gain Parameters Cha
p
ter Six: Remote O
p
eration
82
4. Issue the following command to enter a new gain parameter:
M
x value
ENTER
where
x
= 1 is the gain parameter for set point A
2 is the gain parameter for set point B
3 is the gain parameter for set point C
4 is the gain parameter for set point D
5 is the gain parameter for set point E
value
= gain value (in percent)
5. To check the value of a lead or gain entry, issue the request:
R
xx
ENTER
where
xx
= 41 requests the lead parameter for set point A
42 requests the lead parameter for set point B
43 requests the lead parameter for set point C
44 requests the lead parameter for set point D
45 requests the lead parameter for set point E
46 requests the gain parameter for set point A
47 requests the gain parameter for set point B
48 requests the gain parameter for set point C
49 requests the gain parameter for set point D
50 requests the gain parameter for set point E
If the request is for a
lead
parameter, the 651 controller sends the response:
X
x value
where
x
= 1 is the lead parameter for set point A
2 is the lead parameter for set point B
3 is the lead parameter for set point C
4 is the lead parameter for set point D
5 is the lead parameter for set point E
value
= lead parameter (in seconds)
If the request is for a
gain
parameter, the 651 controller sends the response:
M
x value
where
x
= 1 is the gain parameter for set point A
2 is the gain parameter for set point B
3 is the gain parameter for set point C
4 is the gain parameter for set point D
5 is the gain parameter for set point E
value
= gain parameter (in percent)
