The specifications of a Version 6 terminal are:
Ethernet: Two 100Mbit Full or Half Duplex (Auto Negotiated) ports with
internal hub
Serial Ports: Two ports - Main serial port and Auxiliary serial port. Both
ports support RS232 at speeds of 150, 300, 600, 1200,
2400, 4800, 9600 and 19200 with a user definable parity.
Data bits and Stop bits are pre-set to 8 Data and 1 Stop bit
Inputs: Four optically isolated inputs, normally used for count plus
up to three 'steering' lines, e.g. page size, colour or b&w,
duplex information. The input voltage range is 5v-24v and is
automatically compensated for, not requiring jumpers.
Current may be internally sourced or sourced from an
external device. The interface method is via a D15
connector.
Outputs: Two relays. One relay is configurable for normally open or
normally closed when a session begins. The second relay
is pre-configured as normally open. Other options available
on the output connector are: 0v, 5v reference, Vin (Directly
from the terminal's power connector)
Display: 2 lines by 20 character LCD backlit display
Keys: 20 plastic keys on a rubber keyboard mat
Card Reader: Magnetic Card, Track 2 ABA, HICo or LOCo cards.
External Card Reader Support: Serial Card reader via Aux or Main port, Internal card
reader header supporting both ABA clock and data or
Weigand input
Processor: Mitsubishi M16c/80 running at 18.432MHz
RAM: 1MB
ROM: 512Kb
Power Requirements: 12-24v, 800mA
Power Connector: 2.1mm Center Negative DC Jack
Certifications: FCC, C tick, CE and Canadian Certification
