21Configuration Options
Card Type
Card Setup
Sets the type of card reader attached to the terminal. The options are:
Standard - Normal magnetic card reader
HID - HID Card reader
Wieg26 T1 - See notes below
Wieg26 T2 - See noes below
Impro Wieg - Impro brand Wiegand reader. See notes below.
TDSI - Optical TDSI brand card reader
Wiegand 26 bits (Type 1)
This is referred to as Wieg T1 in the terminal menu system.
The expected format of the data on the card is as follows:
Bit number: 01234567890123456789012345
Byte Groups: SAAAABBBBCCCCDDDDEEEEFFFFP
Parity Mask: XXXXXXXXXXXXXXXXXXXXXXXXE (Even Parity checked on bits 1 - 24)
Card Number Mask: FFFFFFFFNNNNNNNNNNNNNNNN (F=Facility Code, N=Card Number)
The first bit, S, is ignored. The following 24 bits are grouped into six groups of four bits.
Each of the four bits are turned into ascii characters.
The first two bytes are the facility code - these are ignored.
The last four bytes are converted from hexadecimal to decimal, unless a hex number is required.
Wiegand 26 bits - ASP 10022 format (Type 2)
This is referred to as Wieg T2 in the terminal menu system.
The expected format of the data on the card is as follows:
Bit number: 01234567890123456789012345
Byte Groups: PAAAABBBBCCCCDDDDEEEEFFFFP
Parity Mask1 : EXXXXXXXXXXXX (Even Parity checked on bits 1 -
12)
Parity Mask2: XXXXXXXXXXXXE (Even Parity checked on bits 13 - 24)
Card Number Mask:FFFFFFFFNNNNNNNNNNNNNNNN (F=Facility Code, N=Card Number)
The following 24 bits of data are grouped into six groups of four bits.
Each of the four bits are turned into ascii characters.
The first two bytes are the facility code - these are ignored.
The last four bytes are converted from hexadecimal to decimal, unless a hex number is required.
Impro Card Reader 26 Bit Wiegand (IWM904-1-0-GB-01 format)
This is referred to as Impro Wieg in the terminal menu system.
The expected format of the data on the card is as follows:
Bit number: 01234567890123456789012345
Byte Groups: PAAAABBBBCCCCDDDDEEEEFFFFP
