The structure of this Repair Manual reflects the sequence of the working steps for completely disassembling
the dismantled transmission. Dismantling and installing as well as the disassembly and assembly of a main
group are always summarized in one chapter.
Special tools required for performing the respective repair works are
listed under
„Special tools“ See this chapter, 2.0
Important information on industrial safety
Generally, the persons repairing MOXY product-sets are responsible on their own for the industrial safety.
The observation of all valid safety regulations and legal impositions is the pre-condition for avoiding damage to
persons and to the product during maintenance and repair works.
Persons performing repair works must familiarize themselves with these regulations.
The proper repair of these MOXY-products requires the employment of suitably trained and skilled staff.
The repairer is obliged to perform the training.
The following safety references are used in the present Repair Manual:
Serves as reference to special working procedures, methods, information,
the use of auxiliaries etc..
CAUTION Is used, if a deviating and improper working procedure can damage the product.
DANGER:
Is used, if lacking care can lead to personal injury or danger to life.
REFERENCE: Prior to starting the checks and repair works, thoroughly
study the present instructions.
CAUTION: Illustrations, drawings and parts do not always represent the original;
the working procedure is shown. The illustrations, drawings, and
parts are not drawn to scale; conclusions regarding size and weight
must not be drawn (not even within one representation).
The works must be performed according to the description.
REFERENCE:
After the repair works and the checks, the expert staff must
convince itself that the product is properly functioning again.
Structure of the Repair Manual
