Engine
SHOP MANUAL MT26-31 - 06.2005
Tier-3 710655-
Ch 1 page 5
Removal of engine assembly
NOTE!
Place the dump truck on level ground and apply parking brake
Apply articulation lock.
Turn off main switch in battery case.
Raise the dump body and lock it with the safety support.
Raise the tiltable cab and lock it with the safety support
Drain engine coolant
Look in OPERATION & MAINTENANCE MANUAL chapter 2 for instructions.
Take away the cab bolt, left and right hand side.
Nv 46 mm
Turn the direction valve on the pump in lifting up
position.
Place wheel chocks to the front wheel
With the handle, pump and raise the cab.
