Technical Data
PUMP
Admissible operating temperature .............. -40° C to 70° C
1)
Number of outlets ....................................................... 1,2 or 3
Reservoir capacity .................................................. 2 l, 4 l, 8 l
Refilling ................via hydraulic lubrication fitting or from top
Lubricant .................................. greases up to NLGI grade 2
Class of protection ................. IP6K 9K acc. to DIN 40050 T9
................................U
L
type 4X only for indoor use, 12 and 13
6001a02
1)
NOTE
The pump is designed for the above
mentioned temperature range. However,
most times the lubricants are pumpable
up to –25°C only. For lower temperatures
use low-temperature lubricants.
Pump element with fixed lubricant output
Piston diameter, K5, B7..................................................5 mm
- Lubricant output ...................................... approx. 2 cm³/min
Piston diameter, (Standard) K6.......................................6 mm
- Lubricant output ................................... approx. 2.8 cm³/min
Piston diameter, K7, S7..................................................7 mm
- Lubricant output ...................................... approx. 4 cm³/min
Max. operating pressure . ........................................... 350 bar
Connection thread ........................................................ G ¼“
- suitable for tube dia ..................................................... 6 mm
Pump element with adjustable lubricant output
KR ..................................................... 0.04 to 0.18 cm³/stroke
...................................................................... 0.7 to 3 cm³/min
Connection thread ........................................................ G ¼“
- suitable for tube dia ..................................................... 6 mm
- suitable for tube dia ..................................................... 8 mm
6001a02
IMPORTANT
The lubricant outputs listed refer to
grease of NLGI grade 2 measured at
20°C, backpressure 100 bar, and nomi-
nal voltage 12/24 V. Any differing pres-
sures or temperatures result in different
lubricant outputs. Any system design
must be based on the above values.
PRESSURE RELIEF VALVE
SVTE-350-G 1/4A-D6 ........................................ 624-28894-1
SVTE-350-G 1/4A-D8 ........................................ 624-28774-1
TORSION TORQUES
Install pump ................................................................. 18 Nm
Electric motor on housing ............................................ 12 Nm
Pump element in housing ............................................ 25 Nm
Closure plug in housing ............................................... 12 Nm
Return line connector in housing .......................... 10 - 12 Nm
WEIGHTS
The weights below include the following ‘‘individual
weights”:
- Pump kit with one pump element, safety valve, grease
filling (0.75 kg, 1.5 kg)
- Packing (cardboard box)
- Attaching parts
- Operating Instructions
2 l reservoir, standard design (0.75 kg)
- Pump 233, version 2A6.15 ............................ approx. 7.6 kg
4 l reservoir, standard design (1.5 kg)
- Pump 223, 233, version 2A6.15 .................. approx. 10.4 kg
8 l reservoir, standard design (1.5 kg)
-Pump 223, 233, version 2A6.15 ................... approx. 10.6 kg
In the case of pump versions deviating from those mentioned,
add the weights of the following components to the men-
tioned weights:
- per pump element .................................................... +0.2 kg
- per pressure relief valve ........................................... +0.1 kg
- Connection cable with piston detector ...................... +0.1 kg
- Reservoir version ”Filling from top” (only 2 l)
3)
....... +0.15 kg
- 2 l flat-type reservoir.................................................. +0.5 kg
6001a02
3)
NOTE
The 4l and 8l reservoirs have the stan-
dard design ”filling from top”.
