Page 36 of 48
User Manual
Operation Instructions
Subject to modifications
2.1A-30008-A04
LINCOLN GmbH & Co. KG • Postfach 1263 • D-69183 Walldorf • Tel +49 (6227) 33-0 • Fax +49 (6227) 33-259
Troubleshooting, continuation
Fault: The pump does not deliver lubricant
Cause:
Remedy:
Reservoir empty. * LL * display on the membrane keypad
is flashing.
Pump does not deliver lubricant and * Er * display on the
membrane keypad is flashing.
Fill up the reservoir with clean grease. Let the pump run
(trigger additional lubrication cycle, see fig. 30, page19)
until lubricant shows at all lube points.
6001a02
NOTE
Depending on the ambient temperature
and/or sort of lubricant it may take 10 min-
utes of operation before the pump elements
reach their full lubricant output. Therefore,
trigger several additional lube cycles.
Air bubbles in the lubricant Trigger an additional lubrication cycle (see fig. 30, page
19). Loosen the outlet fitting or the main line on the pres-
sure relief valve. The lubricant must penetrate without air
bubbles.
6001a02
NOTE
When push-in type fittings are used, the
high-pressure hose, which is under pres-
sure, cannot be easily disconnected from
the pressure relief valve. For this purpose,
loosen the pressure relief valve or, if exists,
the filling nipple on the pressure relief valve
in order to relieve the high-pressure hose.
Unsuitable lubricant has been used Renew the lubricant (see the lubricant list page 45 and
46).
Suction hole of the pump element clogged Remove pump element. Check suction hole for foreign
particles. If there are any, remove them.
Pump piston worn Replace pump element.
Check valve in the pump element defective or clogged Replace pump element.
