Identification Code – DC Pump Models P233
Examples of model designations
P233 - 4 - X - L - 1 - K6 - 24 - 2A - 6. - 15 - MDF00
P233 - 2 - X - L - BO 1 - K7 - 24 - 2A - 6. - 15 MDF00
P233 - 8 - X - L - BO 1 - K6 - 12 - 2A - 6. - 15 - MDF00
6001a02
NOTE
Any pump combinations other than the follow-
ing standard pumps can be composed and
ordered in accordance with the valid model
identification code.
P233 - 4 - X - L - BO - 1 - K6 - 24 - 2A - 6. - 15 MDF00
Basic pump model for grease
with 1-3 outlets and 12 VDC or 24 VDC motor
Reservoir design
2 = 2 l transparent plastic reservoir
4 = 4 l transparent plastic reservoir
8 = 8 l transparent plastic reservoir
X = Reservoir for grease
L = = Low-level control
without designation = Standard reservoir (2 liters)
BO = Filling from top
Pump elements
1-3 = Number of elements used
K 5 = Piston diameter = 5 mm
K 6 = Piston diameter = 6 mm
K 7 = Piston diameter = 7 mm
KR = Pump element, adjustable, Piston diameter = 7 mm
Connecting voltage
12 or 24 VDC motor
Number of electric connecting possibilities (on pump housing only)
2A = 2 connections:
- connection for power supply on the left, external illuminated pushbutton for
additional lubrication and malfunction
- piston detector on the right
Type of connection
1)
6 = Bayonet plug, 7/5-core, DIN 72585-1
other types of connection possible on request
Connection outside the pump
00 = without socket-outlet, without cable
15 = Bayonet socket with 10 m cable, 7/5-wire
Control p. c. b. s. 12V / 24 V
MDF00 = with microprocessor control, data logger and membrane keypad
