Moxy MT 26 - Measuring Points and Connections

SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 54
56
60
10
30
55
39
67 27 51
29
65
57
53
58
Front
No M easur ing point and va
lue
s
15 To the c ooler
16 Fro
m
the c ooler
28 To
th
e ZF-fil
t
er
29 Fro
m
the fi
lter
30 From the filter b ypa ss to the co
nver
ter
38 From cool
er
lu
bric ati on (via retard
er
valve)
39 In f ront o f c onv. t
o
c
ool
er
(via
r
etarder val
ve
)
40 Af ter c onver te r to c
ooler
(via re tar der val ve)
51
In fr
ont o
f c onv. –
openin
g
pressure 8,5 bar
52 Af ter c onver ter – openi ng pressure 5 bar
53 Clutc h forwar d K V16 + 2 bar
55 Clutc h reverse KR16 + 2 bar
56 Clutc h K 1 16 + 2 ba r
57 Clutc h K 2 16 + 2 ba r
58 Clutc h K 3 16 + 2 ba r
60 Clutc h K 4 16 + 2 ba r
63 Tem p. afte r co nv . ( short tim e 12
0°C)
65 Syst em pres sure 16 + 2 ba r
66 Tem p. after retarder (sho
rt
tim
e
150°C)
67 LU – c ontro
l pr
essure 12 + 2 bar
10
Breather
No. 52
Measuring points and connections
