Ch 2 page 65
TRANSMISSION
Fault
Code
(hex)
MEANING OF THE FAULT
CODE
Possible reason for fault
detection
Reaction of the
TCU
Possible steps
to repair
Remarks
S.C. TO BATTERY
VOLTAGE OR O.C. AT
DLM TRACTION ADJUST
DASHBOARD DEVICE
INPUT
The measured voltage is too
high:
Cable is defective and is
contacted to battery
voltage
Cable has no connection
to TCU
Sensor has an internal
defect
Connector pin is contacted
to battery voltage or is
broken
TCU uses default value
OP-Mode: normal
Check the cable from
TCU to the sensor
Check the connectors
Check the DLM Traction
Adjust dashboard device
S.C. TO GROUND DLM
TRACTION ADJUST
DASHBOARD DEVICE
INPUT
The measured voltage is
too low:
Cable is defective and is
contacted to vehicle
ground
Sensor has an internal
defect
Connector pin is
contacted to vehicle
ground
TCU uses default value
OP-Mode: normal
Check the cable from
TCU to the sensor
Check the connectors
Check the DLM Traction
Adjust dashboard device
S.C. TO BATTERY
VOLTAGE OR O.C. AT DLM
STEERING ANGLE
SENSOR INPUT
The measured voltage is
too high:
Cable is defective and is
contacted to battery
voltage
Cable has no connection
to TCU
Sensor has an internal
defect
Connector pin is
contacted to battery
voltage or is broken
TCU uses default value
OP-Mode: normal
Check the cable from
TCU to the sensor
Check the connectors
Check the DLM
STEERING ANGLE
SENSOR
2C
2D
2E
