SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
Ch 2 page 85
TRANSMISSION
Fault
Code
(hex)
MEANING OF THE FAULT
CODE
Possible reason for fault
detection
Reaction of the
TCU
Possible steps
to repair
Remarks
S.C. TO BATTERY
VOLTAGE AT JOYSTICK
STATUS INDICATOR
TCU detected a wrong
voltage at the output pin,
that looks like a s.c. to
battery voltage
Cable is defective and is
contacted to battery
voltage
Joystick status indicator
has an internal defect
Connector pin is contacted
to battery voltage
No reaction
OP-Mode: normal
Check the cable from
TCU to joystick status
indicator
Check the connectors
from joystick status
indicator to TCU
Check the resistance
1)
of joystick status
indicator
O.C. AT JOYSTICK
STATUS INDICATOR
TCU detected a wrong
voltage at the output pin,
that looks like a o.c. for this
output pin.
Cable is defective and
has no connection to
TCU
Joystick status indicator
has an internal defect
Connector has no
connection to TCU
No reaction
OP-Mode: normal
Check the cable from
TCU to joystick status
indicator
Check the connectors
from joystick status
indicator to TCU
Check the resistance
1)
of joystick status indicator
ENGINE_RETARDER
CONFIG_TIMEOUT
Timeout of CAN-message
ENGINE_RETARDER
CONFIG from EEC
controller
Interference on
CAN-Bus
CAN wire/connector is
broken
CAN wire/connector is
defective an has contact
to vehicle ground or
battery voltage
OP-Mode: substitute
clutch control
Check EEC controller
Check wire of
CAN-Bus
Check cable to EEC
controller
ERC1 TIMEOUT
Timeout of CAN-message
ERC1 from EEC controller
OP-Mode: substitute
clutch control
Check EEC controller
Check wire of CAN-Bus
Check cable to EEC
controller
C5
C6
CA
CB
