SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 284 Ch 2 page 285
TRANSMISSION
TRANSMISSION
Ch 2 page 284 Ch 2 page 285
TRANSMISSION
Figure 561
Figure 563
Figure 562
Separate flange shaft and seal retainer from bearing cover.
(S) Plastic mallet 504196
Press flange shaft out of the ball bearing.
Squeeze circlip out and remove shim.
(S) Set of external pliers 504231
