SHOP MANUAL MT26-31 - 06.2005
Engine
Tier-3 710655-
Ch 1 page 60
Note:
Make sure that the fork clamp and bolt are
dry and free of oil.
4
Place the fork clamp with screw in position
on the unit injector and insert it into the
cylinder head. Press down the unit injector
by hand as far as possible.
5
Torque tighten the bolt to 20 Nm and then a
further 75°. There are two marks on the
rocker cover with a 75° angle between them.
