Setting and Operation, continuation
Operating Mode, continuation
4218a99
after two sec.
4219a99
after two sec.
6252b04
after two sec.
6253b04
after two sec.
4208a04
after approx. 40 sec.
Fig. 43 Operating mode
P3: Number of metering device cycles
Display of the metering device cycles
P4: Programming of the output signal
Display of the output signal “normally closed“ (NC) or “nor-
mally open“ (NO)
Termination of the operating mode
