MSENSE
®
DGA 9 7045899/02 EN – 11.2020 Page 25
• Now align the MSENSE
®
DGA 9 by turning it clockwise until the vent screw is at the 12 o'clock
position at the top. Make sure the device is fitted firmly in this final position.
Remark: The device may only be aligned by turning clockwise. As soon as the device is turned
anti-clockwise for alignment, mounting must be carried out again!
Note!!!
When thread sealing tape is used, screwing the device beyond the 12
o'clock position results in the device having to be screwed back off
again, the thread sealing tape being removed completely and mounting
being carried out again
