Legend
Name
Short designation
(Valve function)
[11]
Flow measurement oil
Flow F1
[12]
Moisture in oil
Moisture in oil
H
2
O
[13]
Oil temperature
Temperature T2
[14]
Filling level sensor zero acknowledgement
Filling level L0
[15]
Temperature heating extraction chamber
-
[16]
Filling level sensor low extraction chamber
Filling level L1
[17]
Filling level sensor high extraction cham-
ber
Filling level L2
[18]
Gas temperature measurement cell
Temperature T1
[19]
Gas-moisture measurement cell
-
[20]
Pressure sensor measurement cell
-
[21]
Temperature heating measurement cell
-
