Overview of possible states:
MSENSE
®
DGA 9 inactive (un-
mounted)
Initialisation cycle
Zero measurement
Vacuum generation
Leak testing
Filling level L1
Degasing
Filling level L2
Gas measurement
Ventilation
Draining
Waiting
The following functions are available in the extraction status menu:
Fault acknowledgement (6.5.1)
Deactivate device (6.5.2)
Activate device (6.5.3)
Exit menu
