USER MANUAL NOVAplus
MRU GmbH, D-74172 Neckarsulm 19 / 95
Base unit with condensate separator
Position
Description
Position
Description
6
Aerial
12
Condensate separator
7
ON-/OFF key button
13
LED condensate sepa-
rator
8
Built-in speed printer
14
Star filter
9
Gas outlet
15
Gas inlet after con-
densate separator
10
Connector T-gas
16
Connector T-Ambient
air (combustion air)
11
Charging socket
17
Charging frame for
Remote control unit
X
Connectors
see also chapter Con-
nectors depending on
the options (conden-
sate separator),Page 20
