USER MANUAL NOVAplus
MRU GmbH, D-74172 Neckarsulm 47 / 95
There are direct measured values available such as Oxygen and Temper-
ature as well as calculated values such as dew point, efficiency and CO
2
.
You will also find the same measurement value in different calculated
values such as CO in ppm or CO in mg/kWh.
Values that cannot be displayed are indicated with dashes. Possible rea-
sons for value not being displayed are:
• Electro chemical sensor was detected as defective during zeroing.
• External temperature sensors are not connected.
The measurement value T-Gas is usually read at the connector “T-
Gas/AUX” (depending on configuration) or if not available from the con-
nector “T1”.
See also Chapter 6 Preparing measurement, Page 40.
There are three measurement windows available, with the arrow keys
left and right moving between them.
