Multilin SR469 - 1.2 ORDER INFORMATION

1. INTRODUCTION ORDER INFORMATION
1-3
Additional features are outlined in Table 1-3.
Table 1-2 METERING
•
Voltage
•
Current and Amps Demand
•
Real Power, kW Demand, kWh power consumption
•
Apparent Power and kVA demand
•
Reactive Power, kvar Demand, kvar consumption/generation
•
Torque
•
Frequency
•
Power Factor
•
RTD
•
Speed in RPM with a Key Phasor Input
•
User Programmable Analog Inputs
Table 1-3 ADDITIONAL FEATURES
•
Drawout Case (for ease of maintenance and testing)
•
Reduced Voltage Starting Control for a Single Transition
•
Trip Coil Supervision
•
Flash memory for easy firmware updates
1.2 ORDER INFORMATION
All features of the SR469 are standard, there are no options. The phase CT secondaries must be specified at the time of order. The
control power and analog output range must also be specified at the time of order. The SR469 differential CT inputs are field
programmable for CTs with 1A or 5A secondaries. There are two ground CT inputs, one for the Multilin 50:0.025 core balance CT and
one for a ground CT with a 1A or 5A secondary, also field programmable. The VT inputs will accommodate VTs in either a delta or wye
configuration. The output relays are always non-failsafe with the exception of the service relay. The SR469 SETUP program is provided
with each unit. A metal demo case may be ordered for demonstration or testing purposes. Other accessories are listed below.
469
469
Basic unit
P1
P5
1A phase CT secondaries
5A phase CT secondaries
LO
HI
DC: 25-60 V; AC: 20-48 V @ 48-62 Hz
DC: 90-300 V; AC: 70-265 V @ 48-62 Hz
A1
A20
0-1 mA analog outputs
4-20 mA analog outputs
***
OTHER ACCESSORIES
469PC Program:
Provided free with each relay
DEMO:
Metal Carry Case in which SR469 unit may be mounted
SR 19-1 PANEL:
Single cutout 19" panel
SR 19-2 PANEL :
Dual cutout 19" panel
SCI MODULE:
RS232 to RS485 converter box designed for harsh industrial environments
Phase CT:
50,75,100,150,200,250,300,350,400,500,600,750,1000
HGF3
,
HGF5, HGF8:
For sensitive ground detection on high resistance grounded systems.
SR469 1
G
GG
G
" Collar:
For shallow switchgear, reduces the depth of the relay by 1 3/8"
SR469 3" Collar:
For shallow switchgear, reduces the depth of the relay by 3"
Optional Mounting Kit:
Additional mounting support 1819-0030
Figure 1-2 SR469 ORDER CODE
