ADDITIONAL FUNCTIONAL TESTING 7. TESTING
7-10
7.3.2 POWER MEASUREMENT TEST
The SR469 specification for reactive and apparent power is ± 1% of √3x2xCTxVTxVT full scale @ Iavg <2xCT. Perform the steps below to
verify accuracy.
1. Alter the following setpoints:
SETPOINT S2:SYSTEM SETUP\CURRENT SENSING\PHASE CT PRIMARY: 1000
SETPOINT S2:SYSTEM SETUP\VOLTAGE SENSING\VT CONNECTION TYPE: Wye
SETPOINT S2:SYSTEM SETUP\VOLTAGE SENSING\VOLTAGE TRANSFORMER RATIO: 10.00:1
2. Inject current and apply voltage as per the table below. Verify accuracy of the measured values. View the measured values in:
ACTUAL VALUES A2:\METERING DATA\POWER METERING
Table 7-15 POWER MEASUREMENT TEST
INJECTED CURRENT
1A UNIT,
APPLIED VOLTAGE
(Ia is reference vector)
INJECTED CURRENT
5A UNIT,
APPLIED VOLTAGE
(Ia is reference vector)
EXPECTED
LEVEL OF
POWER
QUANTITY
TOLERANCE
RANGE
OF POWER
QUANTITY
MEASURED
POWER
QUANTITY
EXPECTED
POWER
FACTOR
MEASURED
POWER
FACTOR
Ia=1A ∠0°
Ib=1A ∠120°
Ic=1A ∠240°
Va=120V ∠342°
Vb=120V ∠102°
Vc=120V ∠222°
Ia=5A ∠0°
Ib=5A ∠120°
Ic=5A ∠240°
Va=120V ∠342°
Vb=120V ∠102°
Vc=120V ∠222°
+ 3424 kW 3329-3519 kW 0.95 lag
Ia=1A ∠0°
Ib=1A ∠120°
Ic=1A ∠240°
Va=120V ∠288°
Vb=120V ∠48°
Vc=120V ∠168°
Ia=5A ∠0°
Ib=5A ∠120°
Ic=5A ∠240°
Va=120V ∠288°
Vb=120V ∠48°
Vc=120V ∠168°
+ 3424 kvar 3329-3519 kvar 0.31 lag
