S1 SR469 SETUP 4. SETPOINT PROGRAMMING
4-10
4.2.8 INSTALLATION
y
#,167$//$7,21
y
#>(17(5@#IRU#PRUH
Õ
ÕÕ
Õ
ENTER
ENTERENTER
ENTER
ESCAPE
ESCAPEESCAPE
ESCAPE
Ö
ÖÖ
Ö 5(6(7#02725
,1)250$7,21=#1R
B1>75*ð>_äðIUc
Û
ÛÛ
Û
ESCAPE
ESCAPEESCAPE
ESCAPE
MESSAGE
MESSAGEMESSAGE
MESSAGE
×
××
×
5(6(7#67$57(5
,1)250$7,21=#1R
B1>75*ð>_äðIUc
FUNCTION:
These commands may be used to clear various information and historical data when the SR469 is first applied on a new installation.
RESET MOTOR INFORMATION:
Counters for number of motor starts and number of emergency restarts can be viewed in Actual Val-
ues. The SR469 also learns various motor characteristics through motor operation. These Learned Parameters include acceleration
time, starting current, and starting thermal capacity. Total motor running hours may also be viewed in Actual Values. On a new installa-
tion or if new equipment is installed, all this information can be reset with this setpoint.
RESET STARTER INFORMATION:
The total number of starter operations can be viewed in Actual Values. On a new installation or if
maintenance work is done on the breaker or contactor, this accumulator can be cleared with this setpoint.
