A1 STATUS 5. ACTUAL VALUES
5-4
speed (2-Speed feature or Assignable Digital Input), phase and ground currents, RTD temperatures, voltages, frequency, power quantities,
and analog inputs. This information can be cleared using the setpoint in S1 SR469 SETUP under CLEAR DATA.
NOTE: Phase, differential and ground currents are recorded 1 cycle prior to the trip. All other pre-trip data is recorded 50 ms prior to the trip.
Thus some values will not be recorded upon instantaneous trips during a start if the trip is less than 50 ms.
