5. ACTUAL VALUES DIAGNOSTICS
5-27
DATA CLEARED SUCCESSFULLY:
Under S1 SR469 SETUP, CLEAR DATA or INSTALLATION, if data is cleared or reset, this mes-
sage will appear to confirm that action.
TOP OF PAGE:
This message will indicate when the top of a page has been reached.
BOTTOM OF PAGE:
This message will indicate when the bottom of a page has been reached.
TOP OF LIST:
This message will indicate when the top of subgroup has been reached.
BOTTOM OF LIST:
This message will indicate when the bottom of a subgroup has been reached.
[.] KEY IS USED TO ADVANCE THE CURSOR:
Any time a setpoint that requires text editing is viewed, this message will appear im-
mediately to prompt the user to use the [.] key for cursor control. If the setpoint is not altered for 1 minute, the message will flash again.
NO ALARMS ACTIVE:
If an attempt is made to enter the Alarm Status message subgroup, but there are no active alarms, this message
will appear.
NO START BLOCKS ACTIVE:
If an attempt is made to enter Start Blocks message subgroup of A1 Actual Values, but there are no
active Start Blocks, this message will appear.
THIS FEATURE NOT PROGRAMMED:
If an attempt is made to enter an actual value message subgroup, when the setpoints are not
configured for that feature, this message will appear.
