6. COMMUNICATIONS MEMORY MAP
6-56
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1DFE Reserved
SPEED2 1DFF Speed2 Standard Overload Curve Number 1 15 1 - F1 4
O/L SETUP 1E00 Speed2 Time to Trip at 1.01 x FLA 5 999999 1 s F10 174145
1E02 Speed2 Time to Trip at 1.05 x FLA 5 999999 1 s F10 34149
1E04 Speed2 Time to Trip at 1.10 x FLA 5 999999 1 s F10 16667
1E06 Speed2 Time to Trip at 1.20 x FLA 5 999999 1 s F10 7954
1E08 Speed2 Time to Trip at 1.30 x FLA 5 999999 1 s F10 5072
1E0A Speed2 Time to Trip at 1.40 x FLA 5 999999 1 s F10 3646
1E0C Speed2 Time to Trip at 1.50 x FLA 5 999999 1 s F10 2800
1E0E Speed2 Time to Trip at 1.75 x FLA 5 999999 1 s F10 1697
1E10 Speed2 Time to Trip at 2.00 x FLA 5 999999 1 s F10 1166
1E12 Speed2 Time to Trip at 2.25 x FLA 5 999999 1 s F10 861
1E14 Speed2 Time to Trip at 2.50 x FLA 5 999999 1 s F10 666
1E16 Speed2 Time to Trip at 2.75 x FLA 5 999999 1 s F10 533
1E18 Speed2 Time to Trip at 3.00 x FLA 5 999999 1 s F10 437
1E1A Speed2 Time to Trip at 3.25 x FLA 5 999999 1 s F10 366
1E1C Speed2 Time to Trip at 3.50 x FLA 5 999999 1 s F10 311
1E1E Speed2 Time to Trip at 3.75 x FLA 5 999999 1 s F10 268
1E20 Speed2 Time to Trip at 4.00 x FLA 5 999999 1 s F10 233
1E22 Speed2 Time to Trip at 4.25 x FLA 5 999999 1 s F10 205
1E24 Speed2 Time to Trip at 4.50 x FLA 5 999999 1 s F10 182
1E26 Speed2 Time to Trip at 4.75 x FLA 5 999999 1 s F10 162
1E28 Speed2 Time to Trip at 5.00 x FLA 5 999999 1 s F10 146
1E2A Speed2 Time to Trip at 5.50 x FLA 5 999999 1 s F10 120
1E2C Speed2 Time to Trip at 6.00 x FLA 5 999999 1 s F10 100
1E2E Speed2 Time to Trip at 6.50 x FLA 5 999999 1 s F10 85
1E30 Speed2 Time to Trip at 7.00 x FLA 5 999999 1 s F10 73
1E32 Speed2 Time to Trip at 7.50 x FLA 5 999999 1 s F10 63
1E34 Speed2 Time to Trip at 8.00 x FLA 5 999999 1 s F10 56
1E36 Speed2 Time to Trip at 10.0 x FLA 5 999999 1 s F10 56
1E38 Speed2 Time to Trip at 15.0 x FLA 5 999999 1 s F10 56
1E3A Speed2 Time to Trip at 20.0 x FLA 5 999999 1 s F10 56
1E3C Reserved
...
1E4F Reserved
1E50 Speed2 Minimum Allowable Line Voltage 70 95 1 % Rated F1 80
1E51 Speed2 Stall Current at Min Vline 200 1500 1 x FLA F3 480
1E52 Speed2 Safe Stall Time at Min Vline 5 9999 1 s F2 200
1E53 Speed2 Accel. Intersect at Min Vline 200 1500 1 x FLA F3 380
1E54 Speed2 Stall Current at 100 % Vline 200 1500 1 x FLA F3 600
1E55 Speed2 Safe Stall Time at 100 % Vline 5 9999 1 s F2 100
1E56 Speed2 Accel. Intersect at 100 % Vline 200 1500 1 x FLA F3 500
