6. COMMUNICATIONS MEMORY MAP
6-58
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1F15 Analog In Differential 1-2 Trip Delay 1 3000 1 s F2 1
1F16 Reserved
... ...
1F1F Reserved
ANALOG 1F20 Analog In Differential 3-4 Enable 0 1 1 - FC126 0
INPUT 3-4 1F21 1
st
and 2
nd
char of Analog In Diff. 3-4 Name 0 65535 1 - F22 ‘An’
DIFF ...
1F26 11
th
and 12
th
char of Analog In Diff 3-4 Name 0 65535 1 - F22 ‘ ‘
. 1F27 Analog In Differential 3-4 Comparison 0 1 1 - FC145 0
1F28 Analog In Differential 3-4 Logic 0 2 1 - FC146 0
1F29 Analog In Differential 3-4 Active When 0 1 1 - FC147 0
1F2A Analog In Differential 3-4 Block from Start 0 5000 1 s F1 0
1F2B Analog In Differential 3-4 Alarm 0 2 1 - FC115 0
1F2C Analog In Differential 3-4 Alarm Relays 0 6 1 - FC113 0
1F2D Analog In Differential 3-4 Percent Alarm 0 500 1 % F1 10
1F2E Analog In Differential 3-4 Absolute Alarm 0 50000 1 Units F1 10
1F2F Analog In Differential 3-4 Alarm Delay 1 3000 1 s F2 1
1F30 Analog In Differential 3-4 Alarm Events 0 1 1 - FC103 0
1F31 Analog In Differential 3-4 Trip 0 2 1 - FC115 0
1F32 Analog In Differential 3-4 Trip Relays 0 6 1 - FC111 0
1F33 Analog In Differential 3-4 Percent Trip 0 500 1 % F1 10
1F34 Analog In Differential 3-4 Absolute Trip 0 50000 1 Units F1 10
1F35 Analog In Differential 3-4 Trip Delay 1 3000 1 s F2 1
1F36 Reserved
... ...
2FFF Reserved
