Multilin SR469 - Page 208

6. COMMUNICATIONS MEMORY MAP
6-60
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
3035 Event Torque 0 9999999 1 Nm/ftlb F2 0
3037 Reserved
…
30DF Reserved
30E0 Event Temp. of Hottest Stator RTD (in Fahr,) -58 482 1
o
FF4 32
30E1 Event Temp. of Hottest Bearing RTD (in Fahr,) -58 482 1
o
FF4 32
30E2 Event Temp. of Hottest Other RTD (in Fahr,) -58 482 1
o
FF4 32
30E3 Event Ambient RTD Temperature (in Fahr,) -58 482 1
o
FF4 32
TRACE 30E4 Reserved
MEMORY ...
30EF Reserved
30F0 Trace Number Selector 1 65535 1 - F1 0
30F1 Trace Memory Channel Selector 0 9 1 - F1 0
30F2 Trace Memory Date N/A N/A N/A N/A F18 N/A
30F4 Trace Memory Time N/A N/A N/A N/A F19 N/A
30F6 Trace Trigger Cause 0 131 1 - FC134 N/A
30F7 Number of Samples per Trace 1 768 1 - F1 N/A
30F8 Number of Traces Taken 0 65535 1 - F1 N/A
30F9 Reserved
30FF Reserved
3100 First Trace Memory Sample -32767 32767 1 - F4 0
... ...
3400 Last Trace Memory Sample -32767 32767 1 - F4 0
3401 Reserved
... ...
3FFF Reserved
