Munters Element - 6 Technical Specifications

© Munters AB, 2018 38
6 Technical Specifications
Power Supply
Mains voltage Single phase, 115/230 VAC
Main fuse 315 mA
Secondary fuse 1 A
Maximum power consumption 22 VA
Available power for peripheral equipment
Inputs/Outputs
6 analog inputs
•
3 analog inputs for temperature sensors
RTS-2 (Thermistor)
•
1 humidity sensor input
0-:-3V
•
2 additional analog inputs
0-:-5V
4 analog outputs 20 mA, 0-:-10V
4 digital inputs Dry contact, 5 V/2 mAmp
Static pressure sensor optional
Relays Outputs
8 Normally Open power relays 2 HP, 12 Amps, 250 VAC
TRIAC Output (optional)
Up to 2 TRIACs
Variable Speed Output:
•
2.2 KW 10 Amps, 230 VAC; 2.8 HP
•
1.1 KW 10 Amps, 115 VAC; 1.4 HP
Housing
Dimensions cm (L x W x H) 40.0 x 27.3 x 16.9
