14 Heating Functions
•
Heating Principles
•
Standard (On/Off) Heating
•
Analog Controlled Heating
14.1 Heating Principles
Heaters are independent; each one can work with its own starting and stopping time, relay selection,
and temperature sensor. In configuring the heaters, you define the temperatures at which the heaters
turn on and off.
•
In Figure 34, the On Temperature is below the target temperature. Heaters remain off until the
temperature falls to the Heat Parameter. When the temperature then rises to the Heat
Temperature, heating stops.
Figure 34: On Temperature below the Target
•
Figure 35 shows a scenario in which the On Temperature is above the Target Temperature.
Heaters remain on until temperatures rise to the Heat Parameter. This scenario would be used
in situations where the animals need extra heat.
Figure 35: On Temperature above the Target
14.2 Standard (On/Off) Heating
Wire heaters to the relays as shown in Figure 7, page 21.
Define Centigrade or Fahrenheit in Measurement System.
1. Go to Control > Heaters.
