Munters Element - Control Method; Position Control

© Munters AB, 2018 62
o
Curtain 1/2: Enter the time it takes to open from 0% to 100% and to close from 100%
to 0%.
4. Configure the opening control mechanism.
12.2 Control Method
•
Position Control
•
Pressure Control
•
Temperature Control
12.2.1 P
OSITION
C
ONTROL
Position control means that the inlets and curtains open to a certain fixed position, based on the
ventilation requirements. Element allows configuring two positions.
1. Go to System > Installation > Inlet & Curtain Setup > Set.
Go to System > Levels of Ventilation > Inlet & Curtain Levels > Set.
2. Define the following parameters:
o
Inlet 1 / 2 start in level: Ventilation level at which Inlets 1 and 2 begin to operate.
o
Inlet Control by: Select Position.
3. Go to System > Levels of Ventilation > Inlet & Curtain Levels and define the opening per levels.
