MUTOH XPJ-461UF - Page 67

Set1: User Type 67
Steps
1. Determine the feed length for the “PF1: Initial Print”, print it, measure the distance between the “+”
marks with a ruler.
2. Enter the distance measured as the “Initial Change”.
3. Determine the feed length for the “PF3: Confirm Print”, print it, and measure the distance between
the “+” marks with a ruler.
•Check that there is no deviation from the feed length.
4. Print a “PF4: Micro Print”, and find the pattern with the least white streaks and image overlaps.
•The numeral below that pattern is the micro adjustment value.
5. Enter the micro adjustment value according to the test pattern print in Step 4.
When you know the adjustment value (when changing the media or for similar operations)
1. Enter the adjustment value for “PF Adjust 5 Micro Change”.
**>3: PF Adjust
Performs media feed adjustment.
• Required media size: width 210 mm × length 110 mm.
• A ruler is required for this adjustment. Please prepare a commercially available
ruler.
When the following defects are found in your prints, they may improve by
conducting a paper feed correction.
•Images are overlapping.
• There are white lines in images.
Submenus
"PF 1. Initial Print" P. 68
"PF2. Initial Change" P. 68
"PF3. Confirm Print" P. 69
"PF4. Micro Print" P. 69
"PF5. Micro Change" P. 70
Type**:3
PFAdjust
**:PFAdjust1
InitialPrint
**:PFAdjust2
InitialChange
**:PFAdjust3
ConfirmPrint
**:PFAdjust4
MicroPrint
**:PFAdjust5
MicroChange
