Menu 1: Setup 69
Manual PF adjustment method using adjustment print.
You will need a ruler to perform this adjustment.
1. Select “PF Adjust 1: Initial Print”.
•“Feed Length: 250 mm” is displayed on the front panel.
2. After the initial adjustment printing, cut the media.
•Measure the distance between the “ ” in the initial adjustment print using a ruler.
3. Refer to Chapter 1 "Media feed adjustment steps" P. 38 and select “PF Adjust 2: Initial Change” on the front panel.
4. Use or on the front panel and enter the measured value in Step 2.
•Tap (Enter) to save the initial adjustment value.
5. Use or on the front panel to select “PF Adjust 3: Confirm Print”.
•“Feed Length: 250 mm” is displayed on the front panel.
6. After the confirmation adjustment printing, cut the media.
•Measure the distance between the “ ” in the confirmation adjustment print using a ruler. Then, confirm
that the distance matches the feeding length when printing.
•If the distance does not match the feeding length, follow the procedure from Step 1 to Step 5 and readjust.
•If the distance matches the feeding length, proceed to Step 7.
7. Refer to Chapter 1 "Media feed adjustment steps" P. 38 and select “PF Adjust 4: Micro Print” on the front panel.
•Check the pattern and micro adjustment value. In the pattern, look for a place that has least white lines or
overlapping in images. The number printed below the adequate pattern is the micro adjustment value.
8. Enter the micro adjustment value according to the printing result in Step 7.
When you know the adjustment value (when changing the media or for similar operations)
1. Enter the adjustment value for “PF Adjust 5: Micro Change”.
2. Select whether you wish to print a confirm pattern and complete the setup.
Note
• Warm up the heater before printing the Confirm and Adjustment patterns.
“Skip Heater Warm Up? No” is displayed on the front panel.
• You can start printing while the printer is warming up.
"Starting printing during warming up" P. 44
