116 Ramp
• Hold the OUT rocker switch until the ramp is fully deployed.
The ramp is fully deployed when the ramp is secured against
the threshold and the cams are locked as shown below. There
will be a two second tone at the end of the deploy cycle. Con-
tinue to hold switch down until the tone has ended.
DO NOT step onto the ramp, or apply a load of any kind to
the ramp surface until it has fully deployed, the cams are
locked and the ramp has fully secured against the threshold.
REASON: Damage to the ramp and serious personal
injury or death could occur.
NOTE: After full deployment on the long ramp, pull up the
manual fence on the upper right side of the ramp to prevent
wheelchair run-off on the top portion of the ramp.
