7197 Series II Owner’s Guide Chapter 6: Commands
August 2011
129
Transmit Printer ID
ASCII
GS I n
Hexadecimal
1D 49 n
Decimal
29 73 n
Value of n
1, 49 = Printer model ID
2, 50 = Type ID
3, 51 = ROM version ID
4, 52 = Logo definition
Transmits the printer ID specified by n as follows:
N Printer ID Specification ID (hexadecimal)
1, 49 Printer model ID NCR 7194 0x24
1, 49 Printer model ID NCR 7193 0x03
1, 49 Printer model ID NCR 7197 Series II 0xA2
2, 50 Type ID Installed options Refer to the table below
3, 51 ROM version ID ROM version 0x00
4, 52 Logo Definition Logo Definition Refer to table below
Type ID (n=2)
Bit Off/On Hex Decimal Function
0 Off 00 0 No two-byte character code installed.
On 01 1 Two-byte character code installed.
1 Off 00 0 No knife installed.
On 02 2 Knife installed.
2 - - - Undefined
3 - - - Undefined
4 Off 00 0 Not used. Fixed to Off.
5 - - - Undefined
6 - - - Undefined
7 Off 00 0 Not used. Fixed to Off.
To Next Page
