7197 Series II Service Manual Chapter 3: Diagnostics
June 2011
57
To stop the test hold the Paper Feed Button down. The printer will return to the Mfg
Adjustment Menu.
Note: Press the Paper Feed Button for at least one second to validate the selection.
Duty check print test (Receipt)
This option let you run duty check printing test. The printer prints the 12.5%, 25%, 50%
and 100% duty original pattern.
Press the Paper Feed Button to start or stop the test.
** START DUTY CHECK PRINT TEST?
Return Main Menu -> Short Click
Start test -> Long Click
1. Enter a Short Click to return to the Mfg Adjustment Menu.
2. Enter a Long Click to begin the Duty Check Print Test.
For Duty Check Print
Stop and exit test -> Short Click
Continue Duty Check Print -> Long Click
Note: Press the Paper Feed Button for at least one second to validate the selection.
