NEC DTL-24D-1 - DT330 - 24 Button Display Digital Phone User Manual

29
CONNECTING LAN CABLE
STEP 1: Prepare 10 BASE-T/100 BASE-T/TX cables
(Straight) for connecting the telephone to net-
work device such as HUB, PoE Switch.
STEP 2: Connect the telephone to the network device
using the LAN cable.
STEP 3: Thread the LAN cable through the groove on
the back of the telephone.
STEP 4: When AC adapter is used to supply power to
the telephone, connect the AC/DC adapter to
the telephone as shown below.
DT730/710
Telephone
To LAN
Groove
LAN Straight Cable
To PC
Telephone
AC Adapter Plug
AC Adapter Cord
Groove
Connector for AC Adapter
