Netafim NMC PRO CLIMATE - System Testing Procedures; TEST RELAY; TEST ANALOG INPUTS; TEST DIGITAL INPUTS

NMC-PRO
USER GUIDE
Doc. Name: NMC-PRO ׀ User Guide Ver 3.05.03 Revision: 2.2 Page: 103
Crop Management Technologies
TEST
TEST RELAY
In this menu, the relays that have been defined under the System Installation – Digital
Outputs (Menu 8.1.1) can be tested manually. The "manual" action turns the relay on. After
a period of five minutes the relay will turn off if left idle.
TEST ANALOG INPUTS
Displays analog inputs as defined in the System Installation – Analog Inputs (Menu 8.1.3)
TEST DIGITAL INPUTS
Displays digital inputs as defined in the System Installation – Digital Inputs (Menu 8.1.2)
VIEW HARDWARE CHECKLIST
HW CHECKLIST
DESCRIPTION LOC. EXP1 EXP2 EXP3
Analog Input
Digital Input
Relay Card
Exp. Box Version
Qty. Climate RTU
2
1
6
--
4
1
1
8
1.0
3
1
1
6
1.0
3
1
1
5
1.0
3
COM Relay
57-64
Relay
56-49
A. In
No. 2
A. In
No. 1
D. In
No. 1
CPU
Relay
1-8
Relay
9-16
Relay
17-24
Relay
25-32
Relay
33-40
P.S.
