MANUAL – HEATING (MENU 2.3)
NETWORK HEATING
1. Network number - The heating network number as defined in System Installation
2. Drive mixing valve (Press Enter to display drop-down menu)
 Auto - Operates as defined by the heating program
 Open - Drives the mixing valve to completely open (100%)
 Closed - Drives the mixing valve to completely closed (0%)
 Fixed - Allows for manually defining the desired water temperature
3. Low Speed Pump (Press Enter to display drop-down menu)
 Auto - Operates as defined by the heating program
 On - Turns low speed pump on (overrides heating program)
 Off - Turns low speed pump off (overrides heating program)
4. High Speed Pump (Press Enter to display drop-down menu)
 Auto - operates as defined by the heating program
 On - turns high speed pump on (overrides heating program)
 Off - turns high speed pump off (overrides heating program)
5. Water fixed temp °C - Define the desired water temperature when the Drive mixing
valve option: FIXED is selected (0.0 - 40.0)
6. Water calc temp °C - Displays the target water temperature
7. Water Meas temp °C - Displays the current water temperature
ON/OFF HEATING
8. Drive ON/OFF heating (Press Enter to display drop-down menu)
 Auto - operates as defined by the heating program
 On - turns on the heating system (Warning! Heater remains on until you
turn it off!)
 Off - turns off the heating system
2.3 Heating manual
Zone 1
19/01/09 16:21
Network Heating
1. Network number
2. Drive mixing valve
3. Low Speed Pump
4. High Speed Pump
5. Fixed water temp °C
6. Calc. water temp °C
7. Meas. water temp °C
1
Auto
Auto
On
---
86
85
2
Open
Auto
Off
---
90
90
ON/OFF Heating
8.
Drive ON/OFF heating
Auto
