Doc. Name: NMC-PRO ׀ User Guide Ver 3.05.03 Revision: 2.2 Page: 49
Crop Management Technologies
STATUS – HEATING (MENU 4.3)
1. Heating temp target – Desired zone temperature
2. Radiation influence – Difference in temp caused by the radiation influence on the
target temperature
3. Cool down influence – Displays the temperature change needed to reach the target
temperature (will always show a negative value)
4. Heat up influence – Displays the temperature change needed to reach the target
temperature (will always show a positive value)
NOTE: The gradual increase/decrease change in temperature for the Cooling and
Heating influences are defined by the time required between periods [defined in
the Heating Program menu (1.3)]
5. Calculated heating temp – Target temperature with all influences considered
6. Temp ON/OFF heat on – Temp at which ON/OFF Heating will turn on
7. Temp ON/OFF heat off – Temp at which ON/OFF Heating will turn off
8. Active for temp – Displays YES if the ON/OFF Heating is in use for increasing the
temperature of the zone
*ONLY when in menu 1.3 Heating Program, parameter Release for temp is set to YES
9. Active for humidity – Displays YES if the ON/OFF Heating is in use for decreasing the
humidity of the zone
*ONLY when in menu 1.3 Heating Program, parameter Release for hum. is set to YES
10. Active for CO2 – Displays YES if CO
2
is active
*ONLY when in menu 7.3.1 Heating ON/OFF Setup, parameter Release for CO2 is set
to YES
11. ON/OFF Heating limitation – Shows if there is a higher priority event restricting the
ON/OFF Heating from operating
2. Radiation influence °C
3. Cool down influence °C
4. Heat up influence °C
5. Calc. heating temp °C
6.
Temp ON/OFF heat on
C
2.5
-1.0
0
18.5
15
13. Min water temp °C
14. Max water temp °C
15. Hum inf. on min temp
16. Calc. water temp °C
17. Meas. water temp °C
0
100
0
85
82
2
100
0
85
85
